► Rotor | Main dimensions
The Main Dimensions menu item is used to define main dimensions of the axial rotor. Main Dimensions are forming the most important basis for all following design steps.
|
|
The real flow in the impeller/rotor is turbulent and three-dimensional. Secondary flows, separation and reattachment in boundary layers, transient recirculation areas and other features may occur. Nevertheless it is useful - and it is common practice in the turbine design theory - to simplify the realistic flow applying representative streamlines for the first design approach. Employing 1D-streamline theory the following cross sections are significant in particular: •inlet (index 1) •outlet (index 2) |
